G3 Series LED Linear High Bay
The Averlite G3 Series LED Linear High Bay is designed for a variety of applications and mounting heights. Wide-angle optics, multiple lumen packages, and color temperatures make it ideal for industrial, commercial, manufacturing, gymnasium, and other applications, that utilize traditional linear fluorescent and HID fixtures. Suggested mounting heights are between 15-25 feet.
Product Specification
| Wattage: | 100W, 200W,240W,300W |
| Power Factor: | >0.95 |
| Voltage: | 100-277v / 200-480V, 50/60hz |
| CCT: | 3500K-5000K |
| Efficacy: | 140lm/W |
| Operating Temperature: | -10°F to + 120°F |
| IP Rating | IP40 |
| Dimming: | 0-10V |
Features
100,000 hours of lifetime.
Superior heat dissipation capability due to the use of multiple heat sinks.
Smooth and uniform light output with no flickering or humming.
Sleek design and Low-profile make it suitable for a wide range of applications.
Savings of up to 75% over conventional fluorescent fixtures.
Resistant to vibration and water.
Inputs voltage range : 100 -277 V or 200 -480 V, 50-60Hz.
Dimming and sensor options available.
CCT & Power Tunable options available.
Packaging Information
| Model Number | Wattage | Fixture Dimensions (IN) |
| 2302D0100WCCL | 100 W | 23.66 x 11.8 x 1.9 |
| 2302d0150WCCL | 150 W | 23.66 x 11.8 x 1.9 |
| 2303D0240WCCL | 200 W | 23.66 x 11.8 x 1.9 |
| 2303D0240WCCL | 240 W | 35.43 x 11.8 x 1.9 |
| 2303D0240WCCL | 300 W | 1187 x 300 x 48 |
